Green MaxTow Quad Gauge Package for 1999-2007 Ford Super Duty Power Stroke

1999-2007 Ford Super Duty Powerstroke MaxTow Custom Diesel Quad Gauge Package
Your Price: $329.99
Item Number:
MT-405-DV-PKG
UPC:
842559106921
Make:
Ford
Model:
Super Duty
Pod:
Quad
Size:
52mm
Mount:
A-Pillar
Color:
Black
Color:
Gray
Color:
Tan
Year Range:
1999 - 2007
Year:
1999
Year:
2000
Year:
2001
Year:
2002
Year:
2003
Year:
2004
Year:
2005
Year:
2006
Year:
2007
Gauge Series:
Black & Green MaxTow Series
Gauge Series:
White & Green MaxTow Series
GoogleTitle:
MaxTow 99-07 Ford 7.3 6.0 PowerStroke Super Duty F250 F350 Green LED Diesel Gauge Set - Quad Pillar Pod & Mounting Kit - Analog & Digital Readings
MaxTow Custom Gauge Package Features:
MaxTow Double Vision Gauge Series
  • Available in 2 1/16th Inch (52mm) Black or White Face with Green Through Dial LED Lighting
  • Double Vision Display Features Both Digital & Analog Gauge Readings
  • Daytime Dimming Mode with 3 Customizable Settings
  • Nighttime Dimming Mode with 3 Customizable Settings
  • Includes All Sensors & Installation Hardware
  • One Year Limited Warranty & Lifetime Technical Support
99-07 Ford Super Duty Quad Pillar Pod
  • Full Size Black, Gray or Tan Quad Pillar Pod
  • Holds Four 2 1/16th Inch (52mm) Gauges
  • Crafted from the Highest Quality ABS Plastic Available
  • Includes Mounting Hardware & Instructions
  • One Year Limited Warranty & Free Lifetime Technical Support
MaxTow Double Vision Gauge Series:
Daytime and Nighttime Dimming Modes Featured with MaxTow Gauges

This MaxTow Custom Gauge Package allows you to select four truck gauges from MaxTow’s Double Vision™ Gauge Series to install with the included truck specific quad pillar pod. The MaxTow Double Vision Gauge Series offers users with a dual readout display that includes a “quick glance” green LED digital display as well as the classic look of an analog gauge through use of the illuminated red needle. Each gauge features a diameter of 2 1/16 inches (52mm) and out performs the competition by utilizing the combination of electronic sensors and stepper motor technology that allows for extremely smooth needle movement and precise gauge readings. MaxTow Gauges also feature daytime (d1, d2, d3) and nighttime (n1, n2, n3) dimming modes where you can set your preferred brightness level whether you’re driving during the day or the late hours of the night! The included brightness recall function remembers the previous brightness setting you had selected before powering your truck down so you won’t have to worry about resetting it every time you power your truck on! MaxTow includes extended wire harnesses for both power (3ft) and sending unit (9ft) connections to ensure you’ll have more than enough for a complete installation!

Don’t forget to take a moment and check out the available gauges and accessories below to see which are recommended for your truck and engine! Get ready to hit the road and Tow to the Max™!

Gauge Options for Powerstroke:
For Ford Diesel Power Stroke applications MaxTow recommends our 60 PSI Boost Gauge, 1500 Degree Exhaust Gas Temperature Gauge, Transmission Temperature Gauge and 100 PSI Fuel Pressure Gauge.
MaxTow 60 PSI Boost Gauge
60 PSI Boost Gauge
  • Electronically Driven
  • Reads Boost from 0-60 PSI
  • Includes 1/8npt Electronic Sensor
  • Includes 9ft of Sensor Wire
MaxTow 1500 F Pyrometer EGT Gauge
1500° Pyrometer EGT Gauge
  • Includes Electronic Exhaust Temperature Probe and Wire Harness
  • Reads Exhaust Temperature from 0-1500 Degrees Fahrenheit
MaxTow Transmission Temperature Gauge
Transmission Temp Gauge
  • Includes Electronic Temperature Sender and Wire Harness
  • Reads Transmission Temperature from 80-260 Degrees Fahrenheit
  • Recommended For Vehicles with Automatic Transmission
MaxTow 100 PSI Fuel Pressure Gauge
100 PSI Fuel Pressure Gauge
  • Includes Electronic 100 PSI Pressure Sender and Wire Harness
  • Reads Fuel Pressure from 0-100 PSI
  • Includes 9ft of Sensor Wire
Other Gauge Options Available:
For gasoline truck applications, MaxTow recommends our 2200 Degree Exhaust Gas Temperature Gauge, 100 PSI Fuel Pressure Gauge, Transmission Temperature Gauge and Water Temperature Gauge.
MaxTow 2200 Exhaust Gas Temperature Gauge
2200° Exhaust Gas Temperature Gauge
  • Includes Electronic Exhaust Temperature Probe and Wire Harness
  • Reads Exhaust Temperature from 200-2200 Degrees Fahrenheit
MaxTow 100 PSI Fuel Pressure Gauge
100 PSI Fuel Pressure Gauge
  • Includes Electronic 100psi Pressure Sender and Wire Harness
  • Reads Fuel Pressure from 0-100 PSI
  • Includes 9ft of Sensor Wire
MaxTow Transmission Temperature Gauge
Transmission Temperature Gauge
  • Includes Electronic Temperature Sender and Wire Harness
  • Reads Transmission Temperature from 80-260 Degrees Fahrenheit
  • Recommended For Vehicles with Automatic Transmission
MaxTow Water Temperature Gauge
Water Temperature Gauge
  • Includes Electronic Temperature Sender and Wire Harness
  • Reads Coolant Temperature from 100-280 Degrees Fahrenheit
Quad Pillar Pod Options:
MaxTow 99-07 Ford Super Duty Powerstroke Pillar Gauge Pods
The included quad pillar pod is specifically designed for the 99-07 Ford Superduty, is available in black, gray, and tan, and is easily mounted to your existing A-pillar giving your Superduty a custom fit and finish. This pod holds four 52mm or 2 1/16th inch gauges, is crafted from the highest quality ABS plastic allowing it to withstand cracking, fading, and warping, and it can also be painted using ABS plastic paint to match your factory interior. MaxTow includes a one year limited warranty and lifetime technical support with every custom gauge package that is purchased.

Fits: 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007 Ford Super Duty, F-250, F-350
1/8-27 NPT Drill & Tap Set
1/8-27 NPT Drill & Tap Set
  • Used for Installing EGT Probe, Boost Fittings or Boost Sensor
  • Drill & Tap Exhaust or Intake Manifold to 1/8-27 NPT
  • Includes Size R Drill Bit & 1/8 NPT Tap
MAP Line T-Fitting Adapter
MAP Line T-Fitting Adapter
  • Quick & Easy Install of Boost Hose or Sensor into the 3/16” MAP Line
  • Cut the Line, Insert the T-Fitting & Secure with Included Clamps
  • Avoid Drilling & Tapping the Intake Manifold
  • Female 1/8-27 NPT Thread for Fittings/Sensor
  • Fits 1999-2002 Ford 7.3L Power Stroke
  • Fits 2003-2007 Ford 6.0L Power Stroke
Air Intake Heater Boost Plug Adapter
Air Intake Heater Boost Plug Adapter
  • Quick & Easy Install of Boost Hose or Sensor to the Air Intake
  • Remove the Restrictive Heater Plug & Thread Adapter in its Place
  • No Drilling or Tapping Required
  • Female 1/8-27 NPT Thread for Fittings/Sensor
  • Fits 1999.5-2002 Ford Super Duty 7.3L Power Stroke
Fuel Pressure Adapter for Ford 6.0L Power Stroke
Fuel Pressure Adapter for Ford 6.0L Power Stroke
  • Quick & Easy Install of Fuel Pressure Sensor to Fuel Filter Housing
  • No Need to Cut Factory Fuel Lines
  • Replaces Pressure Port Fitting
  • Features O-Ring for Leak-Free Seal
  • Female 1/8-27 NPT Thread for Sensor
  • Fits 2003-2007 Ford 6.0L Power Stroke
Fuel Pressure Adapter for Ford 7.3L Power Stroke
Fuel Pressure Adapter for Ford 7.3L Power Stroke
  • Quick & Easy Install of Fuel Pressure Sensor to Fuel Filter Housing
  • No Need to Cut Factory Fuel Lines
  • Replaces Pressure Port Fitting
  • Features O-Ring for Leak-Free Seal
  • Female 1/8-27 NPT Thread for Sensor
  • Fits 1999-2002 Ford 7.3L Power Stroke
1/2 Transmission Cooler Line T-Fitting Adapter
1/2” Transmission Cooler Line T-Fitting Adapter
  • Allows Installation of Temperature Sensor to the 1/2" Transmission Cooler Line
  • Includes T-Fitting, Compression Nuts & Cutting Rings for Leak-Free Seal
  • Female 1/8-27 NPT Thread on T-Fitting for Sensor
3/8 Transmission Cooler Line T-Fitting Adapter
3/8” Transmission Cooler Line T-Fitting Adapter
  • Allows Installation of Temperature Sensor to the 3/8” Transmission Cooler Line
  • Includes T-Fitting, Compression Nuts & Cutting Rings for Leak-Free Seal
  • Female 1/8-27 NPT Thread on T-Fitting for Sensor
HPOP Gauge Wiring Pigtail Harness
HPOP Gauge Wiring Pigtail Harness
  • Quick & Easy Installation Without Having to Splice or Cut into Factory Wires
  • Connects Directly to Injector Control Pressure (ICP) Sensor
  • Plug & Play
  • Fits 1999-2002 7.3L Power Stroke
  • Fits 2003-2007 7.3L Power Stroke
Expandable Circuit
Expandable Circuit
  • Quick & Easy Way to Power Gauges Directly from the Fuse Panel
  • Used for Constant & Switched 12 Volt Power for Gauges
  • Includes 4 Amp Fuse for Circuit Protection
MaxTow 4 Gauge Power Wire Harness
MaxTow 4 Gauge Power Wire Harness
  • Used to Easily Power All 4 Gauges from 1 Harness that Connects to Power
  • Daisy Chain Feature with Each Connector Plugging into Each Gauge
  • Prevents Wire Clutter in Fuse Panel, Under the Hood or in the Pillar Pod
  • 6-1/2’ of Total Wire
